MISSILE SILO
SITE 4
PERSONNEL AND FREIGHT ELEVATOR ENTRANCE
NOTE: CRIB SHOCKS AND DIESEL EXHAUST VENTS ON LEFT
CABLE TRAY FROM LEVEL 2
NOTE: ENTRY AREA TO SILO IN UPPER RIGHT
FAR SIDE OF LEVEL 3
NOTE: SPIRAL STAIRCASE AREA ON LOWER LEFT
CRIB SPRINGS AND STRUTS
OPENING TO FILL AND VENT SHAFT
SPRING HANGER BRACKET
NOTE: EASTERN SILO DOOR MISSING HYDRAULIC RAM
EXHAUST DUCTING FOR DIESEL GENERATORS ONCE LOCATED ON LEVELS 5 AND 6
LEVEL 2 FLOORING REMOVED
NOTE: MISSILE ENCLOSURE AREA HAS BEEN REMOVED
AMF CONTROL BOX FOR THE LAUNCH PLATFORM
LOOKING DOWN ON LEVEL 4
NOTE: SILVER COLORED MATERIAL WAS ONCE PART OF THE MISSILE ENCLOSURE AREA
NORTH SIDE OF THE MISSILE ENCLOSURE AREA
NOTE: BEHIND FOIL BACKED INSULATION MATERIAL WAS THE PERSONNEL AND FREIGHT ELEVATOR
REMAINING BEAMS
LOOKING DOWN WHERE THE SPIRAL STAIRCASE ONCE STOOD
