FLAME DEFLECTION PIT

OPERATIONAL SYSTEMS TEST FACILITY  1

576th  SMS  SITE  F

SIDE OF FLAME DEFLECTOR PIT

NOTE:  LAUNCHER IS ON THE LEFT

LOOKING OVER FLAME DEFLECTOR MOUTH

NOTE:  LAUNCHER ON LEFT

FLAME DEFLECTOR SEPARATED ABOVE GROUND FROM LAUNCHER

NOTE:  SLIDING MISSILE BAY DOOR AND NON-ORIGINAL AIR VENTS INSTALLED

LOOKING DOWN FLAME DEFLECTOR

NOTE:  THIS BELOW GROUND TUNNEL LEADS TO THE FLAME PIT IN THE MISSILE BAY

VIEW OF MISSILE BAY, LOX ROOM AND MECHANICAL AND EQUIPMENT ROOMS FROM FLAME DEFLECTOR
